    RMS12-PH-C60 Magnetic Reed Proximity Sensor NC Reed Switch Proximity Sensor

    Ask Lasest Price
    Brand Name : SUMMIT
    Model Number : RMS12-PH-C60(NC)
    Certification : CE
    Price : USD5-15/PC
    Payment Terms : T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 5000-1000pcs/month
    Delivery Time : 3-20 working days depending on the quantity
    • Product Details
    • Company Profile

    RMS12-PH-C60 Magnetic Reed Proximity Sensor NC Reed Switch Proximity Sensor

    SUMMIT RMS12-PH-C60 Elevator &lift cylinder normally close NC type magnetic sensor magnetic reed leveling proximity switch


    Description:

    Magnetic reed switches are often used to replace mechanically actuated limit switches with plungers, roller and turning levers and as important connecting element for non-contact limit switches. In the elevator industry, magnetic reed switches are used for positioning and control. They are preferably used where mechanically actuated limit switches no longer function satisfactorily due to unfavourable operating conditions such as high or low start-up speeds, high switching frequencies, strong dust or dirt influence, high humidity, chemical atmospheres or large fluctuations in operation intervals.


    Features:

    1. Meet requirements of EN81
    2. Typical application for elevator lift car leveling
    3. Fiber glass reinforced nylon housing, totally closed
    4. Dust-proof, moisture proof
    5. Fixed by particular holder,easy installation and economical
    6. High power switches available
    7. Good performance of anti - interference,more stable
    8. cylindrical Proximity Sensor
    9. NO/NC ,bi stable type contacts available
    10. Customized wire length
    11. Available use with magnet steel or magnetic strip
    12. Also used for motion detection for machine industry
    Mode:RMS12-PH-A10RMS12-PH-A80RMS12-PH-C60RMS12-PH-B80
    EnclosureGlass-fiber PAGlass-fiber PAGlass-fiber PAGlass-fiber PA
    Contact variantsN.ON.ON.C.Bi stable
    Switching voltageMax.150VACMax.250VACMax.230VACMax.230VAC
    Switching currentMax0.5AMax1.3AMax1AMax1A
    Switching capacityMax.10VA/WMax.80VA/WMax.60VA/WMax.80VA/W
    Dielectric strength200V800V400V800V
    Ambient temperature-25℃~+85℃-25℃~+85℃-25℃~+85℃-25℃~+85℃
    Cable length2m2m2m2m

    Elevator reed magnetic sensor RMS12-PH-A10 Size:


    Installation :



    Instruction:

    SUMMIT High Reliability, Inherent in Stringent Quality Control
    brings several decades of expertise in Inductive, Magnetic and Photoelectric Sensors, Phase Monitoring Relays, Electromechanical Relays, Limit Switches and infrared light curtain— enabling us to match different requirements and provide fully customized solutions.
    We provide the comprehensive range of magnetic reed sensors RMS12 series, and enabling us to match different requirements and provide fully customized magnetic sensors and solutions.
